Brazos Island Harbor and Port Isabel Channels

Brazos Santiago Pass
PAGES CHANNEL Station to Station Survey Date(s) PDF Map  XYZ Data
1 - 2 Entrance Channel -20+000 to -6+000 06/24/24 Survey Map XYZ
3 Jetty Channel -6+000 to 0+000 09/17/24 Survey Map XYZ
4 - 6 Channel Across Laguna Madre 0+000 to 20+000 06/24/24 Survey Map XYZ
Brownsville Channel
PAGES CHANNEL Station to Station Survey Date(s) PDF Map  XYZ Data
7 - 9 Junction Basin to Boca Chica Passing Basin 20+000 to 40+000 05/22/24; 07/24/24 Survey Map XYZ
10 - 13 Boca Chica Passing Basin to Goose Island Passing Basin 40+000 to 68+000 05/02/24; 08/29/24 Survey Map XYZ
14 - 15 Goose Island Passing Basin to Brownsville Turning Basin 68+000 to 79+415 05/15/24 Survey Map XYZ
16 Brownsville Turning Basin Extension 79+415 to 86+705 05/16/24 Survey Map XYZ
17 Brownsville Turning Basin 86+705 to 89+500 05/16/24 Survey Map XYZ

Port Isabel Channel
PAGES CHANNEL Station to Station Survey Date(s) PDF Map  XYZ Data
1 Brownsville Channel to Port Isabel via East Wye 13+250 to 19+300 05/20/24 Survey Map XYZ
2 West Wye 0+000 to 5+001.26 05/21/24 Survey Map XYZ
3 Turning Basin 17+803.55 to 22+170.95 05/21/24 Survey Map XYZ
