Sabine Pass to Port Arthur Canal Index & Channel Maps

PAGES CHANNEL Station to Station Survey Date(s) PDF Map XYZ Data
tbd Sabine Bank Channel Extension tbd 04/15,26/25 Survey Map XYZ
1 - 9 Sabine Bank Channel  95+740.87 to 18+091.09 04/04,05/24; 03/26,31/25; 04/26/25 Survey Map XYZ
10 - 11 Outer Bar Channel 18+091.09 to 214+13.87 03/30/25; 05/03/25 Survey Map XYZ
12 - 14 Jetty Channel 214+13.87 to 0+00 03/30/25 Survey Map XYZ
15 - 18 Pass Channel 0+00 to 296+24.44 03/30/25; 04/18/25; 06/03/25 Survey Map XYZ
19 - 22 Port Arthur Canal 0+00 to 279+13 04/22/25; 06/03,11,12/25; 07/09,10/25 Survey Map XYZ
23 Junction-Port Arthur Canal and Sabine Neches River   279+59 to 40+00 09/18/25; 10/02/25 Survey Map XYZ
67 Entrance to Port Arthur Turning Basins 4+81 to 28+34.68 09/09/25 Survey Map XYZ
68 Port Arthur East Turning Basin 0+00 to 17+65 08/20/25 Survey Map XYZ
69 Port Arthur West Turning Basin 28+34.68 to 41+29.53 10/03/25 Survey Map XYZ
70 Channel from Port Arthur West Turning Basin to Taylors Bayou Turning Basin 41+29.53 to 71+47.39 10/03/25 Survey Map XYZ
71 Taylors Bayou Turning Basin 71+47.39 to 105+50 10/03/25 Survey Map XYZ


Port Arthur Canal, Sabine River & Cow Bayou - Index & Channel Maps

PORT ARTHUR CANAL & SABINE RIVER
PAGES CHANNEL Station to Station Survey Date(s) PDF Map  XYZ Data
24 - 30 Junction with Port Arthur Canal to Neches River  40+00 to 593+63.18  05/15,30/25; 06/25/25; 09/05/25 Survey Map XYZ
31 - 33 Neches River to Sabine River (Section B) 0+00 to 230+00 09/24/25 Survey Map XYZ
34 - 37 Sabine River Channel Sec "B" to Orange Turning Basin 230+00 to 586+43 09/03,05/25 Survey Map XYZ
72 -74 Adams Bayou Channel 0+00 to 87+64.94 04/02/25 Survey Map XYZ
38 Orange Turning Basin 586+43 to 623+63.09 09/05/25 Survey Map XYZ
39 Orange Municipal Slip -4+60.83 to 26+34.99 04/25/25 Survey Map XYZ
40 - 41 Orange Turning Basin to Highway 90 Bridge 623+63.09 to 729+38.15 04/04/25 Survey Map XYZ
42 Orange Harbor Island 0+00 to sta. 125+07.12 04/04/25 Survey Map XYZ

COW BAYOU
PAGES CHANNEL Station to Station Survey Date(s) PDF Map  XYZ Data
61 - 65 Cow Bayou Channel -4+00 to 368+00  04/02/25 Survey Map XYZ
66 Orangefield Turning Basin 368+00 to 375+00 04/16/25 Survey Map XYZ


Neches River Index & Channel Maps

PAGES CHANNEL Station to Station Survey Date(s) PDF Map  XYZ Data
44 - 48 Mouth to Smith Bluff Cut-Off 0+00 to 505+00 03/18,20,21/25; 07/22/25; 08/21,29/25; 09/16,22,23/25 Survey Map XYZ
49 - 53 Smiths Bluff to Beaumont Turning Basin 505+00 to 950+15.47 03/21,24/25; 09/15,16/25 Survey Map XYZ
54 Maneuvering Area at Beaumont Turning Basin 950+15.47 to 978+40 09/15/25 Survey Map XYZ
55 Beaumont Turning Basin Extension 978+40 to 998+95.60 03/24/25 Survey Map XYZ
56 Beaumont Turning Basin to Bethlehem Shipyard 998+95.60 to 1037+59.40 09/15/25 Survey Map XYZ
57 Turning Basin at Deer Bayou -1+77 to 25+33 09/22/25 Survey Map XYZ
58 Turning Basin At Smiths Bluff 492+51 to 505+00 09/08/25 Survey Map XYZ
59 Turning Basin at Mile 40.3 690+00 to 705+50 04/03/24; 03/03/25 Survey Map XYZ
60 Channel Extension C 714+20 to 726+54.30 03/03/25 Survey Map XYZ
